Запчасти Komatsu PW130-6K ХОД MTOR¤ ЗАДН. (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

20E-60-K1123

MOTOR ASS'Y,TRAVEL¤ REAR

|1

20E-60-K1122

MOTOR ASS'Y,TRAVEL¤ REAR

1

20E-60-K1540

HOUSING

2

20G-60-K2610

SCREW

|2

20E-60-K1550

PLUG

3

20E-60-K1530

LENS

|4

20E-60-K1510

ROTARY ASS'Y

|4

20E-60-K1560

ROTARY SUB ASS'Y

4

20E-60-K1730

CYLINDER

5

20G-60-K2440

PIN,CENTER

|5

20E-60-K1740

PIN,CENTER

6

20G-60-K2450

PISTON

|6

20E-60-K1750

PISTON

7

20G-60-K2460

COLLAR

|7

20E-60-K1760

COLLAR

8

20G-60-K2470

SPRING

|8

20E-60-K1860

SPRING

9

20G-60-K2490

RING

|9

20E-60-K1880

SEAL

10

20G-60-K2480

PLATE

|10

20E-60-K1870

RETAINER

11

20E-60-K2510

TRAVEL MOTOR ASS'Y

|11

20E-60-K1890

SCREW

12

20E-60-K1570

SHAFT,DRIVE

13

20E-60-K1580

CASE,BEARING

14

20E-60-K1590

COVER

15

20E-60-K1610

NUT

16

20E-60-K1620

PLATE,BACK-UP

17

20E-60-K1630

BEARING

18

20E-60-K1640

BEARING

19

20E-60-K1650

RING,RETAINER

20

20E-60-K1660

RING,SNAP

21

20E-60-K1670

SEAL

22

20E-60-K1680

O-RING

23

20E-60-K1690

SHIM¤ 0.2MM

|23

20E-60-K1710

SHIM¤ 0.3MM

|23

20E-60-K1720

SHIM¤ 0.5MM

24

20E-60-K1520

VALVE ASS'Y

K1

20E-60-K3630

SEAL KIT

|K

20E-60-K1590

COVER

|K

20E-60-K1670

SEAL,RING

|K

20E-60-K1680

O-RING

|K

20E-60-K1990

GASKET

|K

20E-60-K2060

O-RING

|K

20E-60-K2080

O-RING

|K

20E-60-K2090

RING,SEAL

|K

20E-60-K2110

RING,SEAL

|K

20E-60-K2230

O-RING

|K

20E-60-K2380

O-RING

|K

20G-60-K1510

O-RING

|K

20G-60-K1520

NUT,LOCK

|K

20G-60-K2610

SCREW

|K

20G-60-K2720

PLUG

K2

20E-60-K3660

SEAL KIT,DRIVE SHAFT

|K

20E-60-K1590

COVER

|K

20E-60-K1670

SEAL,RING

|K

20E-60-K1680

O-RING
