Запчасти Komatsu PW130-6K МОТОР ХОДА¤ ПЕРЕДН. (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

20E-60-K1113

MOTOR ASS'Y,TRAVEL¤ FRONT

|1

20E-60-K1112

MOTOR ASS'Y,TRAVEL¤ FRONT

|1

20E-60-K2690

VALVE ASS'Y

1

20E-60-K3120

PLATE,VALVE

2

20G-60-K2530

SLEEVE

|2

20E-60-K3130

SLEEVE

3

20G-60-K2540

TRUNNION

|3

20E-60-K3140

TRUNNION

4

20G-60-K1530

RING,BACK-UP

|4

20E-60-K3150

RING,BACK-UP

5

20G-60-K2550

SCREW

|5

20E-60-K3160

SCREW

6

20G-60-K1160

GASKET

|6

20E-60-K3170

GASKET

7

20E-60-K3180

PLUG

8

20G-60-K2560

SCREW

|8

20E-60-K3190

BOLT

9

20E-60-K3210

BOLT

10

20E-60-K3110

STUD

11

20E-60-K3590

NUT

|11

20E-60-K2050

NUT

12

20E-60-K2060

O-RING

13

20G-60-K1510

O-RING

|13

20E-60-K2070

O-RING

14

20E-60-K2080

O-RING

15

20G-60-K2570

RING,SEAL

|15

20E-60-K3260

RING,SEAL

16

20G-60-K1550

RING,SEAL

|16

20E-60-K3270

RING,SEAL

17

20G-60-K2580

PIN

|17

20E-60-K2120

PIN

18

20E-60-K2130

PIN

19

20E-60-K3310

O-RING

20

20G-60-K2610

SCREW

|20

20E-60-K1550

PLUG

|21

20E-60-K3090

COVER ASS'Y,UPPER

21

20E-60-K3510

COVER

22

20E-60-K3520

VALVE

23

20G-60-K2780

SCREW

|23

20E-60-K2370

BOLT

24

20G-60-K1170

O-RING

|24

20E-60-K3540

O-RING

25

20G-60-K2720

PLUG

|25

20E-60-K2250

PLUG

|26

20E-60-K3080

COVER ASS'Y,LOWER

26

20G-60-K2630

HOUSING

|26

20E-60-K3330

HOUSING

27

20G-60-K2640

BUSHING

|27

20E-60-K3340

BUSHING

28

20G-60-K2650

PISTON

|28

20E-60-K3350

PISTON

29

20E-60-K3360

BUSHING

30

20E-60-K3370

SCREW

31

20G-60-K2680

SPRING

|31

20E-60-K3380

SPRING

32

20E-60-K3390

SPRING

33

20G-60-K1430

O-RING

|33

20E-60-K3410

O-RING

34

20G-60-K2710

SCREW

|34

20E-60-K3420

BOLT

35

20G-60-K2720

PLUG

|35

20E-60-K2250

PLUG

36

20G-60-K2730

RING,RETAINER

|36

20E-60-K2260

RING,RETAINER

37

20G-60-K1490

STUD

|37

20E-60-K2270

STUD

38

20E-60-K3460

PIN

39

20G-60-K1520

NUT

|39

20E-60-K2290

NUT

40

20E-60-K2310

PIN

41

20E-60-K2320

RING,RETAINER

42

20E-60-K2540

PLUG,(NOT SHOWN)
