Запчасти Komatsu PW130-6K ХОД MTOR¤ ПЕРЕДН. (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

20E-60-K1113

MOTOR ASS'Y,TRAVEL¤ FRONT

|1

20E-60-K1112

MOTOR ASS'Y,TRAVEL¤ FRONT

1

20E-60-K2710

HOUSING

2

20E-60-K1550

PLUG

3

20E-60-K2720

LENS,CONTROL

|4

20E-60-K2680

ROTARY ASS'Y

|4

20E-60-K2740

ROTARY SUB ASS'Y

4

20G-60-K2430

CYLINDER

|4

20E-60-K2910

CYLINDER

5

20G-60-K2440

PIN,CENTER

|5

20E-60-K2920

PIN,CENTER

6

20G-60-K2450

PISTON

|6

20E-60-K2930

PISTON

7

20G-60-K2460

COLLAR

|7

20E-60-K2940

COLLAR

8

20G-60-K2470

SPRING

|8

20E-60-K3040

SPRING

9

20G-60-K2490

RING

|9

20E-60-K3060

SEAL

10

20G-60-K2480

PLATE

|10

20E-60-K3050

RETAINER

11

20G-60-K2510

SCREW

|11

20E-60-K1890

SCREW

12

20G-60-K2310

SHAFT,DRIVE

|12

20E-60-K2750

SHAFT,DRIVE

13

20E-60-K2760

CASE,BEARING

14

20G-60-K2330

COVER

|14

20E-60-K2770

COVER

15

20G-60-K2340

NUT

|15

20E-60-K2780

NUT

16

20G-60-K2350

PLATE,BACK-UP

|16

20E-60-K2790

PLATE,BACK-UP

17

20G-60-K2360

BEARING

|17

20E-60-K2810

BEARING

18

20G-60-K2370

BEARING

|18

20E-60-K2820

BEARING

19

20G-60-K2380

RING,RETAINER

|19

20E-60-K2830

RING,RETAINER

20

20G-60-K1210

RING,SNAP

|20

20E-60-K2840

RING,SNAP

21

20G-60-K1260

RING

|21

20E-60-K2850

SEAL

22

20G-60-K1390

O-RING

|22

20E-60-K2860

O-RING

23

20G-60-K2390

SHIM

|23

20E-60-K2870

SHIM¤ 0.1MM

|23

20G-60-K2410

SHIM

|23

20E-60-K2880

SHIM¤ 0.3MM

|23

20G-60-K2420

SHIM

|23

20E-60-K2890

SHIM¤ 0.5MM

24

20E-60-K2690

VALVE ASS'Y

25

20E-60-K2660

VALVE ASS'Y,RELIEF

26

20E-60-K2670

VALVE ASS'Y,BRAKE

K-1

20E-60-K3670

SEAL KIT,(WITHOUT BRAKE VALVE)

|K

20E-60-K2080

O-RING

|K

20E-60-K3310

O-RING

K-2

20E-60-K3640

SEAL KIT,RELIEF VALVE

|K

20E-60-K3150

RING,BACK-UP

|K

20G-60-K1160

GASKET

|K

20G-60-K1170

O-RING

|K

20G-60-K1260

RING,SEAL

|K

20G-60-K1390

O-RING

|K

20G-60-K1430

O-RING

|K

20G-60-K1510

O-RING

|K

20G-60-K1520

NUT,NUT

|K

20G-60-K1550

RING,SEAL

|K

20G-60-K2330

COVER

|K

20G-60-K2570

RING,SEAL

|K

20G-60-K2610

SCREW,DRAIN

|K

20G-60-K2720

PLUG,SCREW

K

20G-60-K3680

REPAIR PARTS,DRIVE SHAFT

|K

20G-60-K1260

RING,SEAL (FOR SHAFT)

|K

20G-60-K1390

O-RING

|K

20G-60-K2330

COVER

K

20E-60-K3640

SEAL KIT,RELIEF VALVE

|K

20E-60-K4310

SEAL,PISTON

|K

20E-60-K4320

O-RING

|K

20E-60-K4330

O-RING

|K

20E-60-K4340

RING,THRUST

|K

20E-60-K4350

O-RING

|K

20E-60-K4360

O-RING

|K

20E-60-K4370

O-RING
