Запчасти Komatsu PW128UU-1 РУКОЯТЬ И ЛИНИЯ КОВША ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
1
201-62-71810
JOINT
2
07002-22434
O-RING
|2
07002-12434
O-RING
3
07230-20522
UNION
4
07002-22434
O-RING
|4
07002-12434
O-RING
5
21J-62-12251
HOSE Z030001A0A
|5
21J-62-12250
HOSE Z030001A0
5A
08210-02905
SPIRAL TUBE Z030001A0
|5A
08210-01804
SPIRAL TUBE Z030001A0
6
08210-02906
SPIRAL TUBE
|6
08210-01805
SPIRAL TUBE
7
203-62-66131
TEE
8
07002-22434
O-RING
|8
07002-12434
O-RING
9
07230-20628
UNION
|9
07230-20522
UNION
10
07002-22434
O-RING
|10
07002-12434
O-RING
11
21J-62-15171
HOSE Z030001A0A
|11
21J-62-12240
HOSE Z030001A0
12
08210-01802
SPIRAL TUBE
|12
08210-01805
SPIRAL TUBE
13
201-62-64330
ELBOW
14
07002-21423
O-RING
|14
07002-11423
O-RING
15
21J-62-15710
NIPPLE
16
11T-09-11280
NIPPLE
17
07002-21823
O-RING
|17
07002-11823
O-RING
18
21J-62-12890
HOSE¤ 370MM
|18
21J-62-12880
HOSE
19
201-62-71820
JOINT
20
07002-22434
O-RING
|20
07002-12434
O-RING
21
232-60-14271
NIPPLE
22
07002-22434
O-RING
|22
07002-12434
O-RING
23
21J-62-12271
HOSE Z030001A0A
|23
21J-62-12270
HOSE Z030001A0
23A
08210-01808
SPIRAL TUBE
|23A
08210-01804
SPIRAL TUBE
24
08210-01805
SPIRAL TUBE
25
203-62-61410
JOINT
26
07002-22434
O-RING
|26
07002-12434
O-RING
27
07230-20628
UNION
|27
203-62-32510
NIPPLE
28
07002-22434
O-RING
|28
07002-12434
O-RING
29
21J-62-12262
HOSE Z030001A0A
|29
21J-62-12260
HOSE Z030001A0
30
08210-02906
SPIRAL TUBE
|30
08210-01805
SPIRAL TUBE
|30
08210-01805
SPIRAL TUBE
Выбрано товаров: 55
