Запчасти Komatsu PW128UU-1 ТРАНСМИССИЯ (УПРАВЛЯЮЩ. КЛАПАН) ТРАНСМИССИЯ И КОМПОНЕНТЫ

|1

21J-15-00010

TRANSMISSION ASS'Y

|1

21J-15-15001

CONTROL VALVE ASS'Y

1

21J-15-15131

SEAT,VALVE

|2

21J-15-15101

ECMV ASS'Y

|2

21J-15-15100

ECMV ASS'Y

2

ECMV GROUP

|2

ECMV GROUP

3

BRACKET

4

07000-72015

O-RING (K2)

5

07000-71009

O-RING (K2)

6

07000-71006

O-RING (K2)

7

01252-70650

BOLT

8

21J-15-15152

BLOCK

|8

21J-15-15151

BLOCK

9

700-71-55001

RELIEF VALVE ASS'Y,RELIFE (SEE FIG.Y1672-11A0)

10

07000-73032

O-RING (K2)

11

01252-71030

BOLT

12

01643-51032

WASHER

13

712-85-11721

FILTER ASS'Y

|13

712-85-11720

FILTER

14

712-85-11731

ELEMENT ASS'Y

|14

712-85-11730

ELEMENT ASS'Y

15

07000-02060

O-RING (K2)

16

07000-73022

O-RING (K2)

17

07000-72015

O-RING (K2)

18

07040-11812

PLUG

19

07002-01823

O-RING (K2)

20

01011-81035

BOLT

21

01643-51032

WASHER

22

01010-81085

BOLT

23

01643-51032

WASHER

24

07043-00108

PLUG

25

07043-00211

PLUG

26

700-11-31980

PLATE¤ NAME

27

07000-73022

O-RING (K2)

28

07000-71009

O-RING (K2)

29

07000-71006

O-RING (K2)

30

07000-72012

O-RING (K2)

31

07000-72015

O-RING (K2)

32

01010-81050

BOLT

33

01643-51032

WASHER
