Запчасти Komatsu PW128UU-1 ЗАГРУЗОЧН. КЛАПАН(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21J-60-13122

VALVE ASS'Y,CHARGE

|1

21J-60-13120

VALVE ASS'Y,CHARGE

1

UC1100469432

BODY

2

UC1100519803

SPOOL

3

UC1100485764

RETAINER

4

UC1100485755

VALVE SEAT

5

UC1100485737

PISTON

6

UC1100485746

POPPET

7

UC1801469506

SCREW,ADJUST

8

UC1100519812

GUIDE

9

UC1100425607

SPOOL

10

UC1100425616

GUIDE

11

UC1100469459

PLUG

12

UC1801442602

NUT

13

UC1800012769

SHIM

14

UC1100426527

SPRING

15

UC1192181003

SPRING

16

UC1100469469

SPRING

17

UC1303007169

BALL

18

UC1198273704

PLUG

19

UC1198273603

PLUG

20

UC1800044537

O-RING

21

UC1303039139

O-RING

22

UCJ2020K9529-0

RELIEF VALVE

23

UC1100111858

ORIFICE

24

UC1701538687

PLUG

25

UC1701538797

PLUG

26

UC1100081115

NAME PLATE

27

UC1303024274

SCREW

28

UC1100268826

PLUG

29

UC1100268817

PLUG

30

UC1100469818

PLUG

31

UC1100426875

SPRING

32

UC1100435484

GUIDE

33

UC1100471691

FILTER

34

UC1100409366

RING,SNAP

35

UC1198273502

PLUG

36

UC1303026032

O-RING

37

UC1303026096

O-RING

38

UC1303026078

O-RING
