Запчасти Komatsu PW128UU-1 ТРАНСМИССИЯ (BARE¤ /) ТРАНСМИССИЯ И КОМПОНЕНТЫ

|1

21J-15-00010

TRANSMISSION ASS'Y

1

21J-15-11131

HOUSING,2ND CLUTCH

2

113-15-22760

PISTON

3

113-15-29220

RING,SEAL (K1)

4

113-15-29250

RING,SEAL (K1)

4A

198-15-26510

PLUG

5

21J-15-12311

CARRIER

6

21J-15-12410

GEAR

7

113-15-29410

BEARING

8

113-15-32560

WASHER,THRUST

|9

21J-15-00130

SHAFT ASS'Y

9

SHAFT

10

566-15-41320

PLUG

11

04025-00312

PIN,SPRING

12

21J-15-12111

SHAFT

13

04064-04018

RING,SNAP

14

06000-06008

BEARING

15

21J-15-12582

SPACER

|15

21J-15-12581

SPACER

15A

07018-10803

RING

16

07018-11305

RING,SEAL

17

21J-15-12210

GEAR

18

04064-04518

RING,SNAP

19

21J-15-12220

GEAR

20

01252-40616

BOLT

21

21J-15-12320

CARRIER

22

21J-15-12611

GEAR,RING

23

712-83-19510

RING,SNAP

24

103-15-22420

GEAR

25

103-15-29420

BEARING

26

113-15-32560

WASHER,THRUST

27

21J-15-12520

SHAFT

28

04025-00312

PIN,SPRING

29

712-83-11270

PIN

30

113-15-22720

PLATE

31

113-15-42711

DISC

32

113-15-22730

PLATE

33

113-15-22920

SPRING

34

04020-01024

PIN,DOWEL
