Запчасти Komatsu PW128UU-1 МОТОР ХОДА (ПЕРЕДН.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21J-60-11160

MOTOR ASS'Y,TRAVEL

|1

UC4100470851

ROTARY GROUP

1

UC1100470863

SHAFT

2

UC1704098788

CYLINDER BLOCK

3

UC1704098797

PIN

4

UC1704268116

PISTON

5

UC1708318866

RING

6

UC1100182337

PLATE

7

UC1704098825

GUIDE

8

UC1704098834

SPRING

9

UC1100504746

SEAL

10

UC1100028435

PLATE

11

UC1302168007

RING,SNAP

12

UC1303027237

RING,SNAP

13

UC1704329835

SHIM

14

UC1300297002

O-RING

15

UC1100503669

SEAL,OIL

16

UC1179033905

BEARING

17

UC1708316209

SCREW

18

UC1700635035

PIN

19

UC1704098953

SHIM

20

UC1100241812

SHIM

|20

UC1100132185

SHIM

|20

UC1100295194

SHIM

|20

UC1100295204

SHIM

21

UC1100132185

SHIM

22

UC1100028509

DISTANCE PIECE

23

UC1100028499

DISTANCE PIECE

24

UC1100099693

NUT

25

UC1182964007

SHIM

|25

UC1100295323

SHIM

|25

UC1100134879

SHIM

26

UC1100470845

HOUSING

27

UC1100028673

COVER

28

UC1300293009

O-RING

29

UC1301567009

BOLT
