Запчасти Komatsu PW128UU-1 ЦИЛИНДР ОПОРЫ (ВНУТР. ЧАСТИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21J-63-X2150

CYLINDER ASS'Y,OUTRIGGER. L.H.

|G1

21J-63-X2160

CYLINDER ASS'Y,OUTRIGGER. R.H.

|1

20G-63-12101

CYLINDER ASS'Y,OUTRIGGER. L.H.

|1

20G-63-12201

CYLINDER ASS'Y,OUTRIGGER. R.H.

|1

20G-63-12110

CYLINDER SUB ASS'Y

1

20G-63-12141

CYLINDER

2

20G-63-12120

ROD,PISTON

3

707-27-11271

HEAD,CYLINDER

4

707-56-70540

SEAL,DUST (KIT)

5

07179-00093

RING,SNAP

6

07177-07030

BUSHING

7

707-51-70211

PACKING,ROD (KIT)

8

07000-12105

O-RING (KIT)

9

707-35-91111

RING,BACK-UP (KIT)

10

01010-51655

BOLT

11

707-36-11360

PISTON

12

707-44-11180

RING,PISTON (KIT)

13

07155-01125

RING,WEAR (KIT)

14

07165-15252

NUT

15

707-76-70040

BUSHING

16

07145-00070

SEAL,DUST (KIT)

17

20G-63-12171

TUBE,L.H.

|17

20G-63-12271

TUBE,R.H.

18

20G-63-12181

TUBE,L.H.

|18

20G-63-12281

TUBE,R.H.

19

07000-13030

O-RING (KIT)

20

01010-50855

BOLT

21

01010-50845

BOLT

22

01602-20825

WASHER,SPRING

23

707-88-99170

BRACKET

24

707-88-99120

BAND

25

01010-51030

BOLT

26

01602-21030

WASHER,SPRING

27

07283-22236

CLIP

28

01599-01011

NUT

29

01643-31032

WASHER

30

07020-00000

FITTING,GREASE

31

07020-00900

FITTING,GREASE

KIT

707-98-37500

SERVICE KIT,OUTRIGGER CYLINDER
