Запчасти Komatsu PW128UU-1 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (ДЛЯ MONO СТРЕЛА)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

21J-63-X2230

CYLINDER GROUP

|1

202-63-02332

CYLINDER ASS'Y,BUCKET

1

202-63-74542

CYLINDER,BUCKET

2

707-76-65210

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

707-27-90620

HEAD,CYLINDER

6

707-52-90350

BUSHING

7

707-51-60030

PACKING,ROD (KIT)

8

707-51-60630

RING,BUFFER (KIT)

9

07000-15085

O-RING (KIT)

10

707-35-90960

RING,BACK-UP (KIT)

11

141-63-93270

SEAL,DUST (KIT)

12

07179-12074

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

202-63-74320

ROD

16

707-76-65220

BUSHING

17

707-77-65110

SEAL,DUST (KIT)

18

07020-00675

FITTING,GREASE

19

707-36-90300

PISTON

20

707-44-90180

RING,PISTON (KIT)

21

707-39-90110

RING,WEAR (KIT)

22

707-44-90911

RING

23

07165-14244

NUT,NYLON

24

202-63-74373

TUBE

25

202-63-74580

TUBE

26

07000-13025

O-RING (KIT)

27

01010-50850

BOLT

28

01643-50823

WASHER

29

707-88-96280

BAND

30

202-63-74390

BRACKET

31

01010-51035

BOLT

32

01643-51032

WASHER

33

01010-51025

BOLT

34

01643-31032

WASHER

KIT

707-98-27600

SERVICE KIT,BUCKET CYLINDER
