Запчасти Komatsu PW128UU-1 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) (ДЛЯ OFFSET СТРЕЛА)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XZ340

CYLINDER GROUP,ARM (FINAL COATING)

|G1

707-01-XA090

CYLINDER GROUP,ARM (NATURAL YELLOW)

|1

21Y-63-02720

CYLINDER ASS'Y,ARM

1

21Y-63-62540

CYLINDER,ARM

2

707-76-80180

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

21Y-63-62520

ROD,PISTON

5

707-76-70230

BUSHING

6

07145-00070

SEAL,DUST (KIT)

7

07020-00000

FITTING,GREASE

8

707-27-11971

HEAD,CYLINDER

9

707-52-90500

BUSHING

10

707-51-75030

PACKING,ROD (KIT)

11

707-51-75630

RING,BUFFER (KIT)

12

07000-15105

O-RING (KIT)

13

707-35-91150

RING,BACK-UP (KIT)

14

144-63-94170

SEAL,DUST (KIT)

15

07179-13089

RING,SNAP

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-11661

PISTON

19

707-44-11280

RING,PISTON (KIT)

20

707-39-11510

RING,WEAR (KIT)

21

707-44-11920

RING

22

707-71-60200

PLUNGER

23

04260-00635

BALL

24

707-71-91270

CAP

25

01310-01216

SCREW

26

07000-15070

O-RING (KIT)

27

707-35-90360

RING,BACK-UP (KIT)

28

707-83-13010

VALVE

29

07750-01628

SPRING

30

707-87-14070

PLUG

31

07002-12034

O-RING (KIT)

32

707-86-46690

TUBE

33

21Y-63-62171

TUBE

34

07000-13025

O-RING (KIT)

35

01010-80850

BOLT

36

01643-50823

WASHER

37

707-88-95350

BAND

38

21Y-63-62191

BRACKET

39

01010-81035

BOLT

40

01643-51032

WASHER

41

07283-22236

CLIP

42

01599-01011

NUT

43

01643-31032

WASHER

KIT

707-99-44280

SERVICE KIT,ARM CYLINDER
