Запчасти Komatsu PW128UU-1 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) (ДЛЯ 2 ЧАСТИ СТРЕЛА)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21J-63-X2532

CYLINDER GROUP

|1

21J-63-02531

CYLINDER ASS'Y,ARM

1

21J-63-62341

CYLINDER,ARM

2

707-76-70160

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-71-32550

COLLAR

5

07000-15120

O-RING (KIT)

6

707-35-91320

RING,BACK-UP (KIT)

7

707-27-13910

HEAD,CYLINDER

8

707-52-90610

BUSHING

9

707-51-85030

PACKING,ROD (KIT)

10

707-51-85630

RING,BUFFER (KIT)

11

07000-15120

O-RING (KIT)

12

707-35-91320

RING,BACK-UP (KIT)

13

707-56-85510

SEAL,DUST (KIT)

14

07179-13099

RING,SNAP

15

01010-81670

BOLT

16

01643-51645

WASHER

17

21J-63-62321

ROD

18

07020-00675

FITTING,GREASE

19

707-71-60260

PLUNGER

20

04260-00635

BALL

21

707-71-91270

CAP

22

707-76-80010

BUSHING

23

07145-00080

SEAL,DUST (KIT)

24

707-71-60860

PLUNGER

25

707-36-13400

PISTON

26

707-44-13180

RING,PISTON (KIT)

27

707-39-13110

RING,WEAR (KIT)

28

707-44-13911

RING

29

01310-01216

SCREW,NYLON

29A

07000-15070

O-RING (KIT)

29B

707-35-90930

RING,BACK-UP (KIT)

29C

707-83-13010

VALVE

29D

07750-01628

SPRING

29E

707-87-14070

PLUG

30

07002-12034

O-RING (KIT)

31

21J-63-62370

TUBE

32

21J-63-62181

TUBE

33

07000-13030

O-RING (KIT)

34

01435-01055

BOLT

35

01435-01040

BOLT

36

707-88-95081

BAND

37

21J-63-62191

BRACKET

38

01010-81035

BOLT

39

01643-51032

WASHER

40

07283-32738

CLIP

41

01599-01011

NUT

42

01643-31032

WASHER

KIT

707-99-46630

SERVICE KIT,ARM CYLINDER
