Запчасти Komatsu PW128UU-1 ЦИЛИНДР 2-Й СТРЕЛЫ (ВНУТР. ЧАСТИ) (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21J-63-X2350

CYLINDER GROUP,2ND BOOM

|1

21J-63-02350

CYLINDER ASS'Y

1

21J-63-53340

CYLINDER,BOOM

2

707-76-80370

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

21J-63-53320

ROD,PISTON

5

707-76-80370

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-16130

HEAD,CYLINDER

8

07179-13094

RING,SNAP

9

195-63-92190

SEAL,DUST (KIT)

10

707-52-90560

BUSHING

11

707-51-80030

PACKING,ROD (KIT)

12

07000-15150

O-RING (KIT)

13

07146-05152

RING,BACK-UP (KIT)

14

707-51-80630

RING,BUFFER (KIT)

15

01010-81660

BOLT

16

01643-51645

WASHER

17

707-36-16400

PISTON

18

707-44-16180

RING,PISTON (KIT)

19

07156-01620

RING,WEAR (KIT)

20

07000-12060

O-RING (KIT)

21

707-35-52900

RING,BACK-UP (KIT)

22

707-40-16170

SPACER

22A

01010-61240

BOLT

23

21J-63-53380

TUBE

24

21J-63-53370

TUBE

25

01435-01055

BOLT

26

01435-01040

BOLT

27

07000-13030

O-RING (KIT)

28

21J-63-53390

BRACKET

29

707-88-21190

BAND

30

01010-81240

BOLT

31

01643-51232

WASHER

32

07283-32236

CLIP

33

01599-01011

NUT

34

01643-31032

WASHER

KIT

707-99-62050

SERVICE KIT,2ND BOOM
