Запчасти Komatsu PW128UU-1 1-Я СТРЕЛА ЦИЛИНДР (ВНУТР. ЧАСТИ) (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21J-63-X2500

CYLINDER GROUP,BOOM L.H.

|G1

21J-63-X2301

CYLINDER GROUP,BOOM L.H.

|G1

21J-63-X2510

CYLINDER GROUP,BOOM R.H.

|G1

21J-63-X2311

CYLINDER GROUP,BOOM R.H.

|1

21J-63-02500

CYLINDER ASS'Y,BOOM

|1

21J-63-02300

CYLINDER ASS'Y,BOOM

1

21J-63-52740

CYLINDER

|1

21J-63-52141

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

707-27-95921

HEAD,CYLINDER

|5

707-27-95620

HEAD,CYLINDER

6

707-52-90420

BUSHING

|6

707-52-90400

BUSHING

7

707-51-65030

PACKING,ROD (KIT)

8

707-51-65630

RING,BUFFER (KIT)

9

07000-15085

O-RING

|9

07000-15090

O-RING (KIT)

10

707-35-90970

RING,BACK-UP

|10

07001-05090

RING,BACK-UP (KIT)

11

144-63-92170

SEAL,DUST (KIT)

12

07179-12079

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

21J-63-52720

ROD

|15

21J-63-52120

ROD

16

707-76-70230

BUSHING

17

07145-00070

SEAL,DUST (KIT)

18

707-36-95531

PISTON

|18

707-36-95410

PISTON

18A

707-34-55020

O-RING (KIT)

18B

707-35-90610

RING,BACK-UP (KIT)

19

707-44-95180

RING,PISTON (KIT)

20

707-39-95120

RING,WEAR (KIT)

21

707-44-95911

RING

22

01310-01016

SCREW

|22

07165-14547

NUT,NYLON

23

21J-63-52770

TUBE,L.H.

|23

21J-63-52170

TUBE,L.H.

|23

21J-63-52870

TUBE,R.H.

|23

21J-63-52270

TUBE,R.H.

24

21J-63-52180

TUBE,L.H.

|24

21J-63-52280

TUBE,R.H.

25

07000-13025

O-RING (KIT)

26

01010-80850

BOLT

27

01643-50823

WASHER

28

707-88-96950

BAND

29

21J-63-52191

BRACKET

30

01010-81035

BOLT

31

01643-51032

WASHER

32

01010-81030

BOLT

33

01643-31032

WASHER

KIT

707-98-36250

SERVICE KIT,1ST BOOM

|KIT

707-98-36200

SERVICE KIT,1ST BOOM
