Запчасти Komatsu PW128UU-1 ОСНОВН. НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21J-60-11131

MAIN PUMP ASS'Y

1

CAM

2

TM0824-051

CAP

3

TM0321-040

CAP

4

TM0205-902

O-RING

5

SERVO CASE

6

TM0205-501

O-RING

7

TM8072-083

BOLT

8

TM1220-291

PISTON

9

SERVO COVER

10

TM1220-286

PISTON

11

TM8072-087

BOLT

12

TM8072-104

BOLT

13

TM0824-050

CAP

14

TM0205-809

O-RING

15

TM0205-401

O-RING

16

TM8072-142

BOLT

17

TM1238-225

ROD

18

TM1220-288

PISTON

19

TM0890-002

FILTER

20

TM0769-113

BLOCK

21

TM1290-318

SPRING

22

O-RING

23

TM1203-336

COVER

24

TM1299-302

STOPPER

25

TM0859-216

RING¤ BACK-UP

26

TM0205-808

O-RING

27

TM1299-303

CAP

28

TM0205-806

O-RING

29

TM8110-071

NUT

30

TM8008-453

SCREW

31

TM1291-215

BUSH

32

TM0205-601

O-RING

33

TM8040-122

BOLT

34

TM8130-002

WASHER

35

TM1028-057

COUPLING

36

ADAPTER

37

HOUSING

38

TM1014-039

DRIVE GEAR

39

TM1015-511

WEAR PLATE

40

TM0682-114

NEEDLE BEARING

41

TM1015-512

WEAR PLATE

42

TM0522-050

PIN,DOWEL

43

TM0205-402

O-RING

44

TM1014-521

GEAR

45

TM0859-201

RING¤ BACK-UP

46

TM0201-091

O-RING

47

TM0535-065

BOLT

48

TM0131-008

WASHER¤ SPRING

49

TM8072-092

BOLT

50

TM8072-086

BOLT

51

TM0769-114

SPACER

52

TM8022-102

PIN

53

TM0205-802

O-RING

54

TM0205-801

O-RING
