Запчасти Komatsu PW128UU-1 ОПОРА (РАМА) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21J-47-12110

FRAME

2

04052-01664

PIN

3

130-75-17160

CHAIN

4

430-43-26520

PIN

5

20E-47-13120

FRAME

6

21K-70-11210

BUSHING

7

07145-00070

SEAL,DUST

8

20G-47-13180

BUSHING

9

07145-00045

SEAL,DUST

10

07020-00900

FITTING,GREASE

11

21J-47-12120

PLATE

12

20G-47-13140

PIN

13

04082-00514

LOCK

14

01010-81435

BOLT

15

01643-31445

WASHER

16

20G-47-13150

PIN

17

01011-81220

BOLT

18

01643-31232

WASHER

19

20G-47-13161

PIN

20

04082-00514

LOCK

21

01010-81435

BOLT

22

01643-31445

WASHER

23

07020-00000

FITTING,GREASE

24

20G-47-13170

PIN

25

04082-00212

LOCK

26

01010-81225

BOLT

27

01643-31232

WASHER

28

21J-47-12130

COVER

29

01010-81020

BOLT

30

01643-31032

WASHER

31

20E-47-13130

COVER

32

01010-81020

BOLT

33

01643-31032

WASHER

34

287-46-11670

SPACER

35

01011-82400

BOLT

36

01643-32460

WASHER

37

20D-47-43130

PIN

38

04082-00212

LOCK

39

01010-81225

BOLT

40

01643-31232

WASHER

41

20E-47-13140

PLATE¤ OPERATING,OUTRIGGER
