Запчасти Komatsu PW128UU-1 РУКОЯТЬ (ДЛЯ MONO СТРЕЛА) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

21J-70-00410

ARM ASS'Y

1

ARM

2

203-70-56130

BUSHING

3

203-70-42182

BUSHING

4

203-70-56150

BUSHING

5

07020-00000

FITTING,GREASE

6

07020-00900

FITTING,GREASE

7

21J-62-15460

HOSE

|7

07096-20510

HOSE

|7

07096-20509

HOSE

8

07096-20410

HOSE

|8

07096-20409

HOSE

9

203-70-42121

PIN

10

203-46-56270

PLATE

11

01010-81230

BOLT

12

01643-31232

WASHER

13

07020-00675

FITTING,GREASE

14

21Y-70-14830

SPACER¤ 1.0MM

|14

203-70-41460

SPACER¤ 1.0MM

15

21Y-70-14840

SPACER¤ 2.0MM

|15

203-70-41470

SPACER¤ 2.0MM

16

202-70-52121

PIN

17

21Y-70-14710

SPACER¤ 1.0MM

|17

202-70-48460

SPACER¤ 1.0MM

18

203-46-56270

PLATE

19

01010-81230

BOLT

20

01643-31232

WASHER

21

07145-00070

SEAL,DUST

22

203-70-33210

SEAL,DUST
