Запчасти Komatsu PW128UU-1 MONO СТРЕЛА (НАВЕСНОЕ ОБОРУД-Е) (ДЛЯ -ACTUATER НАВЕСН. ОБОРУД)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21J-70-12840

TUBE

|1

21Y-70-16110

TUBE

2

21J-973-2540

TUBE

2A

21J-973-2550

TUBE

3

21J-70-12850

TUBE

|3

21Y-70-16130

TUBE

4

21J-973-1862

TUBE

5

07372-21045

BOLT

6

07372-21055

BOLT

6A

07372-21030

BOLT

7

01643-51032

WASHER

8

07000-B3030

O-RING

9

07372-21045

BOLT

10

07372-21055

BOLT

11

01643-51032

WASHER

12

07000-B3030

O-RING

13

07371-30640

FLANGE,SPLIT

14

07372-21035

BOLT

15

01643-51032

WASHER

16

07000-B3025

O-RING

17

21J-62-14470

BRACKET

|17

203-62-64370

BRACKET

18

21J-973-2670

CLAMP

|18

201-973-6730

CLAMP

19

01010-81070

BOLT

20

01643-31032

WASHER

21

21J-62-14470

BRACKET

|21

203-62-64370

BRACKET

22

21J-973-2670

CLAMP

|22

201-973-6730

CLAMP

23

01010-81070

BOLT

24

01643-31032

WASHER

25

21J-62-14480

BRACKET

|25

203-62-64310

BRACKET

26

01010-81035

BOLT

27

01643-31032

WASHER

28

21J-973-2670

CLAMP

|28

201-973-6730

CLAMP

29

01010-81025

BOLT

30

01643-31032

WASHER

31

07040-12012

PLUG

32

07002-22034

O-RING

33

07040-11007

PLUG

34

07002-21023

O-RING

35

21J-62-14490

BRACKET

|35

203-62-64272

BRACKET

36

01010-81035

BOLT

37

01643-31032

WASHER

38

21J-973-2670

CLAMP

|38

201-973-6730

CLAMP

39

01010-81025

BOLT

40

01643-31032

WASHER
