Запчасти Komatsu PW128UU-1 2-СЕКЦИОНН. СТРЕЛА (ГИДРАВЛ ЛИНИЯ И СМАЗЫВАЮЩ. ЛИНИЯ¤ /) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21J-62-15212

TUBE

|1

21J-62-15211

TUBE

2

21J-62-15221

TUBE

3

21J-62-17710

HOSE

|3

21J-62-15230

HOSE¤ 1250MM

4

21J-62-15241

HOSE

|4

21J-62-15240

HOSE¤ 1400MM

5

21J-62-15250

HOSE¤ 780MM

6

21J-62-17720

HOSE¤ 1290MM

|6

21J-62-15260

HOSE¤ 1290MM

7

21J-62-15320

HOSE¤ 1430MM

8

21J-62-15330

HOSE¤ 840MM

9

21J-70-11861

CLAMP

|9

21Y-70-14271

CLAMP

10

21J-70-11832

CLAMP

|10

21J-70-11830

CLAMP

11

21J-70-11841

CLAMP

|11

21J-70-11840

CLAMP

12

01011-81010

BOLT

13

01010-81030

BOLT

14

01643-31032

WASHER

15

21J-62-14510

CLAMP

|15

203-62-64430

CLAMP

|15

203-70-53380

CLAMP

16

01010-81025

BOLT

17

01643-31032

WASHER

18

21J-973-2680

CLAMP

|18

203-973-5660

CLAMP

|18

203-973-5660

CLAMP

18A

21J-973-2670

CLAMP

|18A

201-973-6730

CLAMP

19

01010-81025

BOLT

20

01643-31032

WASHER

21

21J-62-15281

BRACKET

|21

21J-62-15280

BRACKET

22

01010-81220

BOLT

23

01643-31232

WASHER
