Запчасти Komatsu PW128UU-1 ПЕРЕДН. ПРИВОД (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

21J-22-00012

FRONT DRIVE ASS'Y,L.H.

|1

21J-22-00011

FRONT DRIVE ASS'Y,L.H.

|1

21J-22-00022

FRONT DRIVE ASS'Y,R.H.

|1

21J-22-00021

FRONT DRIVE ASS'Y,R.H.

1

21J-50-11112

KNUCKLE,L.H.

|1

21J-50-11122

KNUCKLE,R.H.

2

21J-22-11162

SPINDLE,L.H.

|2

21J-22-11172

SPINDLE,R.H.

3

21J-22-11560

RING

4

21J-22-11580

ELBOW

5

07002-01423

O-RING

6

07043-70108

PLUG

|6

07043-00108

PLUG

7

21J-22-11210

CARRIER

8

21J-22-11330

GEAR

9

09232-02519

BEARING

10

201-26-71270

WASHER,THRUST

11

21J-22-11340

PIN

12

20S-26-71250

PIN

13

22W-15-22570

WASHER,THRUST

14

21J-22-11310

COUPLING

15

04065-02812

RING,SNAP

16

21J-22-11320

GEAR

17

21J-22-11360

GEAR,RING

18

19M-30-13180

O-RING

19

01010-81865

BOLT

|19

01010-81865

BOLT

19A

01010-81870

BOLT

20

01643-31845

WASHER

20A

21J-22-11670

PLATE

20B

21J-22-11680

COVER

20C

01010-81220

BOLT

20D

01643-31232

WASHER

21

21J-22-11262

HUB,WHEEL

22

20G-22-22350

BEARING

23

21J-22-11190

SEAL,OIL

24

21J-22-11231

DISC

25

21J-22-11511

TUBE

26

01010-81440

BOLT

27

01643-31445

WASHER

28

07043-70108

PLUG

|28

07043-00108

PLUG

29

21J-22-11270

PISTON

30

124-15-41910

RING,SEAL

31

23A-15-19210

RING,SEAL

32

21J-22-11111

HUB

33

06002-32022

BEARING
