Запчасти Komatsu PW128UU-1 ЗАДН. МОСТ (ЗАДНИЙ ДИФФЕРЕНЦИАЛ) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

21J-23-11500

REAR AXLE ASS'Y

|1

21J-23-11003

REAR AXLE ASS'Y

|1

21J-23-11001

REAR AXLE ASS'Y

|1

21J-23-11200

PINION AND GEAR

1

PINION

2

GEAR

3

21J-23-11130

CAGE

4

07000-12130

O-RING

5

22T-22-11830

BEARING

6

21J-23-11640

BEARING

7

21J-23-11270

SPACER

8

22T-22-11230

COUPLING

9

01010-61490

BOLT

10

361-21-11710

PLATE

11

07000-13032

O-RING

12

07012-50058

SEAL

13

21J-23-11180

PROTECTOR

|14

21J-23-11100

CARRIER¤CAP ASS'Y

14

CARRIER

15

CAP

16

423-22-11161

PIN

17

01010-61485

BOLT

18

20G-22-11180

WASHER

19

01010-61025

BOLT

20

22T-22-21370

SHIM¤ 0.05MM

|20

22T-22-21380

SHIM¤ 0.2MM

|20

22T-22-21390

SHIM¤ 0.5MM

21

22T-22-11900

PARKING BRAKE ASS'Y,(SEE FIG.P1450-52A0)

22

20G-22-11420

SPIDER

23

20G-22-11410

PINION

24

20G-22-11430

GEAR

25

20G-22-11440

WASHER

26

20G-22-11450

WASHER

|27

20D-22-41150

CASE ASS'Y

27

20K-22-11130

CASE

28

20D-22-41140

CASE

29

01010-61070

BOLT

30

20G-22-11510

BEARING

31

01010-61435

BOLT

32

01643-31445

WASHER

33

20G-22-11160

RING

34

04050-16050

PIN

35

20G-22-11710

SCREW

36

01583-12012

NUT

37

20K-22-11190

O-RING

38

01010-61440

BOLT

39

01643-31445

WASHER

40

04020-01434

PIN
