Запчасти Komatsu PW128UU-1 ПРАВ. КОРПУС (/)(№-) ЧАСТИ КОРПУСА

1

21J-54-12112

COVER

1A

01010-81020

BOLT

1B

01643-31032

WASHER

2

21J-54-12191

BRACKET

3

01010-81225

BOLT

4

01643-31232

WASHER

5

21J-54-12121

COVER

6

01010-81225

BOLT

7

01643-31232

WASHER

7A

09415-02512

CAP

8

21J-54-12151

BRACKET

9

01010-81225

BOLT

10

01643-31232

WASHER

11

21J-54-12131

COVER

12

01010-81225

BOLT

13

01643-31232

WASHER

|14

21J-54-12200

COVER ASS'Y

14

COVER

15

09415-00506

CAP

16

21J-54-12161

BAR

17

01641-20812

WASHER

18

04052-10833

PIN

19

21J-54-12350

BRACKET

20

20B-54-12210

SPRING

21

01023-10408

SCREW

22

205-54-53550

DOVE TAIL

23

01010-80616

BOLT

24

01643-30623

WASHER

25

21Y-54-11321

PLATE

26

01010-81225

BOLT

27

01643-31232

WASHER

28

205-60-71220

LOCK ASS'Y

29

21J-54-12282

COVER

30

01643-51232

WASHER

30A

01010-81225

BOLT

30B

01643-31232

WASHER

31

20R-54-11460

SPRING

|31

417-54-17132

SPRING

32

01023-60412

SCREW

|32

01023-60408

SCREW
