Запчасти Komatsu PW128UU-1 ТОПЛИВН. БАК. ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

|1

21J-04-00013

FUEL TANK ASS'Y

|1

21J-04-00012

FUEL TANK ASS'Y

|1

21J-04-00011

FUEL TANK ASS'Y

|1

21J-04-00010

FUEL TANK ASS'Y

1

21J-04-11114

TANK

1

FUEL TANK

|1

FUEL TANK

|1

FUEL TANK

2

20Y-04-21220

GAUGE

|2

21S-04-11151

GAUGE

3

20N-60-41371

GASKET

4

20N-60-41360

BOLT

5

21J-04-11160

PLUG

6

21J-04-11170

CAP ASS'Y

6A

21J-04-11210

STRAINER

7

22T-04-11410

STRAINER

8

22T-04-11420

PACKING

9

21J-04-11152

FLOAT

|9

21J-04-11220

FLOAT

|9

21J-04-11150

FLOAT

10

01023-60510

SCREW

|10

01023-10512

SCREW

11

21J-04-11311

BAND ASS'Y

|11

21J-04-11310

BAND ASS'Y

11A

01580-11210

NUT

11B

01643-31232

WASHER

12

01010-81225

BOLT

13

01643-31232

WASHER

14

21J-04-11133

STAY

|14

21J-04-11132

STAY

15

201-968-1470

ELBOW

16

07281-00259

CLAMP

17

21J-04-11241

HOSE

|17

21J-04-11240

HOSE

18

21J-04-11260

NIPPLE

|18

142-04-13190

NIPPLE

19

01010-81020

BOLT

|19

01010-81025

BOLT

20

01643-31032

WASHER

21

07281-00259

CLAMP

22

07700-50345

VALVE

|22

20Y-04-11130

VALVE

23

201-968-1470

ELBOW

|23

205-04-62130

ELBOW

24

07285-00155

CLIP

|24

07281-00197

CLAMP

25

07288-21001

HOSE

|25

07288-21010

TUBE
