Запчасти Komatsu PW128UU-1 ОСНОВН. КОНСТРУКЦИЯ (РУЛЕВ. УПРАВЛЕНИЕ COLUME) (НАКЛОН. РУКОЯТЬ)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

21J-40-13220

BRACKET

2

21J-06-13112

SWITCH ASS'Y

3

01023-60616

SCREW

4

21J-40-13164

COVER

|4

21J-40-13163

COVER

5

01023-60816

SCREW

6

21J-40-13280

COVER

7

01023-60816

SCREW

8

569-06-61131

SWITCH,WIPER AND WASHER

9

01023-60516

SCREW

9

21J-06-13780

COVER

10

23S-05-55550

SWITCH,EMERGENCY STEERING

11

21J-06-13610

SWITCH,BRAKE MODE

12

21J-40-11270

PLATE

13

01023-70512

SCREW

14

21J-40-13231

BRACKET

15

01010-81040

BOLT

16

01010-81025

BOLT

17

01643-31032

WASHER

18

21J-40-13270

BRACKET

19

20D-40-41150

KNOB

20

01580-11411

NUT

21

21J-40-13250

SHAFT

22

04205-12042

PIN

23

04050-15030

PIN

24

01640-22032

WASHER

25

20D-40-41190

PLATE

26

21J-40-13211

COLUMN

27

21J-40-13121

SHAFT

28

21J-40-13130

BEARING

29

04065-03715

RING

30

04064-02012

RING

31

21J-40-13150

SEAT

32

21J-40-13140

RING

33

08037-01008

GROMMET

34

01582-11210

NUT

35

01641-21223

WASHER

36

01010-81030

BOLT

37

01643-31032

WASHER

38

08034-00519

BAND
