Запчасти Komatsu PW128UU-1 ОСНОВН. КОНСТРУКЦИЯ (ОСНОВ.¤ /) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

21J-54-13331

BRACKET,R.H.

|1

21J-54-13330

BRACKET,R.H.

2

01010-81025

BOLT

3

01643-31032

WASHER

4

21J-54-13171

PLATE

|4

21J-54-13170

PLATE

5

01010-81020

BOLT

6

01643-31032

WASHER

7

09304-10835

KNOB

8

104-43-25190

YOKE

|8

04210-20624

YOKE

|8

04210-20500

YOKE

9

01580-10605

NUT

|9

01580-10504

NUT

10

21J-54-13180

BOSS

11

01010-81025

BOLT

12

01643-31032

WASHER

13

21J-54-13150

LINK

14

20U-43-21121

SHAFT

15

01010-80616

BOLT

16

01643-30623

WASHER

17

195-61-34120

BEARING

18

09311-41237

BUMPER

19

01580-11210

NUT

20

21J-54-13160

LINK

21

20U-43-21121

SHAFT

22

01010-80616

BOLT

23

01643-30623

WASHER

24

195-61-34120

BEARING

25

21J-54-13140

LEVER

26

195-61-34120

BEARING

27

21J-54-13320

ROLLER

28

09350-01420

BUSHING

29

04050-14028

PIN,COTTER

30

01641-21423

WASHER

31

20Y-54-13550

SPRING

32

20T-54-71460

SPRING

33

04050-12015

PIN,COTTER

34

01643-30823

WASHER

35

04205-10822

PIN

36

21J-54-13191

SPRING,LOOSE

|36

21J-54-13190

SPRING,LOOSE

37

04205-10514

PIN

|37

04205-10514

PIN

38

04052-10530

PIN,SNAP

|38

04052-10530

PIN,SNAP

38A

04205-10516

PIN

38B

04050-11210

PIN,COTTER

39

21J-54-13130

BRACKET,L.H.

40

22X-54-12370

SPRING

41

01023-60516

SCREW
