Запчасти Komatsu PW128UU-1 КАБИНА (/) (КАБИНА) (С ВЕРХН. ЗАЩИТА)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

21J-54-00101

CAB ASS'Y,(WITH HEAD GUARD)

|1

21J-54-00100

CAB ASS'Y,(WITH HEAD GUARD)

1

CAB ASS'Y,GUARD

|1

CAB ASS'Y,GUARD

2

22U-54-14620

PACKING

3

21J-54-14751

WINDOW,L.H. UPPER Z050001A0

4

20U-54-24971

DAM,L.H. UPPER

5

21J-54-14762

WINDOW,L.H. LOWER Z050001A0

6

21J-54-16140

NUT

7

21J-54-16150

PACKING

8

01010-D0810

BOLT

9

01643-70823

WASHER

10

20U-54-24981

DAM,L.H. LOWER

11

21J-54-14860

LINING,REAR

12

21J-54-14871

LINING,L.H.

13

21J-54-14882

LINING,R.H.

14

20U-54-25170

SEAL

15

21J-54-14711

GLASS,R.H. Z050001A0

16

21J-54-14720

DAM,R.H.

17

21J-54-14733

CLEAR PLATE,ROOF Z050001A0

18

21J-54-14662

SEAL,ROOF

19

20T-54-74870

NUT

|19

205-54-51720

RETAINER

20

20T-54-74880

GROMMET

21

01643-71232

WASHER

22

01224-40610

SCREW

23

22X-54-19260

LOCK,QUARTER

24

01224-40510

SCREW

25

01584-30504

NUT

26

21J-54-14850

HINGE

27

01224-70620

SCREW

28

01584-30605

NUT

29

21J-54-16510

GLASS,REAR Z050001A0

|29

21J-54-14770

GLASS,REAR Z050001A0

30

205-54-51720

RETAINER

31

205-54-51730

PACKING,REAR

32

01224-40610

SCREW

33

21J-54-16530

SEAL,REAR

|33

21J-54-14740

SEAL,REAR

34

21J-54-16270

CURTAIN ASS'Y

35

01435-40612

BOLT

36

20U-54-25640

LOCK,QUARTER

37

01224-40510

SCREW

38

01584-30504

NUT
