Запчасти Komatsu PW128UU-1 КАБИНА (/) (КАБИНА)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

21J-54-00011

CAB ASS'Y

|1

21J-54-00010

CAB ASS'Y

1

CAB

|1

CAB

2

22U-54-14620

PACKING

3

21J-54-14751

WINDOW,L.H. UPPER Z050001A0

4

20U-54-24971

DAM,L.H. UPPER

5

21J-54-14762

WINDOW,L.H. LOWER Z050001A0

6

21J-54-16140

NUT

7

21J-54-16150

PACKING

8

01010-D0810

BOLT

9

01643-70823

WASHER

10

20U-54-24981

DAM,L.H. LOWER

11

21J-54-14860

LINING,REAR

12

21J-54-14871

LINING,L.H.

13

21J-54-14882

LINING

14

20U-54-25170

SEAL,R.H.

15

21J-54-14711

GLASS,R.H. Z050001A0

16

21J-54-14720

DAM

17

21J-54-14733

CLEAR PLATE,ROOF Z050001A0

18

21J-54-14662

SEAL,ROOF

19

01643-71232

WASHER

20

20T-54-74880

GROMMET

21

01224-40610

SCREW

22

21J-54-16331

GUARD

|22

21J-54-16330

GUARD

23

21J-54-16341

BRACKET

24

21J-54-16350

BRACKET

25

01010-B0616

BOLT

|25

01010-B0616

BOLT

26

01643-30623

WASHER

|26

01643-30623

WASHER

27

22X-54-19260

LOCK,QUARTER

|27

20U-54-25640

LOCK,QUARTER

28

01224-40510

SCREW

29

01584-30504

NUT

30

21J-54-14850

HINGE

31

21J-54-16360

SPACER

32

08037-01610

GROMMET

33

01224-70620

SCREW

34

01584-30605

NUT

35

21J-54-16510

GLASS,REAR Z050001A0

|35

21J-54-14770

GLASS,REAR Z050001A0

36

205-54-51720

RETAINER

37

205-54-51730

PACKING,REAR

38

01224-40610

SCREW

39

21J-54-16530

SEAL,REAR

|39

21J-54-14740

SEAL,REAR

40

21J-54-16270

CURTAIN ASS'Y

41

01435-40612

BOLT

42

20U-54-25640

LOCK,QUARTER

43

01224-40510

SCREW

44

01584-30504

NUT
