Запчасти Komatsu PW118MR-8 СТАРТЕР, .KW, ВНУТР. ЧАСТИ ДВИГАТЕЛЬ ЭЛЕКТРИКА

\0.99

600-813-4461

STARTING MOTOR, ASSEMBLY 4.5KW

1

ND028100-2881

YOKE, ASSEMBLY

2

ND028062-0130

COVER

3

ND028099-3570

STARTING MOTOR KIT

4

ND028200-1590

ARMATURE, ASSEMBLY

5

ND949100-1930

BEARING, BALL

6

ND949100-1750

BEARING, BALL

7

ND028300-5091

CLUTCH, ASSEMBLY

\7.94

ND028099-3310

STATOR, KIT

\7.95

ND028300-6750

CLUTCH, ASSEMBLY

\7.96

ND949100-4500

BEARING, BALL

\7.97

ND949100-1920

BEARING, BALL

\7.98

ND949170-4040

SPRING

\7.99

ND028381-0071

SHAFT

8

ND228401-1440

HOUSING, ASSEMBLY

9

ND153400-2192

MAGNET, ASSEMBLY

\9.94

ND128099-5830

STARTING MOTOR KIT

\9.95

ND028099-3160

STARTING MOTOR KIT

\9.96

ND053660-0443

PLUNGER

\9.97

ND053404-0240

GASKET

\9.98

ND053505-0290

COVER

\9.99

ND053480-7560

BOLT, ASSEMBLY

10

ND028510-5390

HOLDER ASSEMBLY, BRUSH

11

ND949173-0571

SPRING

12

ND028501-7880

FRAME

13

ND128961-0010

BALL

14

ND949170-4070

SPRING

15

ND028371-1500

PINION

16

ND028306-0070

ROLLER

17

ND028063-0030

RETAINER

18

ND028327-0171

RETAINER

19

ND949042-3741

BOLT

20

ND90804-10050

O-RING

21

ND949011-5700

WASHER

22

ND90801-10050

O-RING

23

ND949007-6530

SCREW

24

ND949020-0600

WASHER

25

ND90170-10061

NUT

26

ND90258-10001

WASHER, SPRING

27

ND949017-1290

WASHER

28

ND90258-06001

WASHER

29

ND949006-6910

SCREW

30

ND90200-06241

WASHER

31

ND028062-5790

COVER

32

ND90260-00501

WASHER

33

ND949007-6850

SCREW

34

ND028901-5190

SEAL

35

ND949056-4480

NUT
