Запчасти Komatsu PW110R-1 ПЕРЕДНИЙ МОСТ (/) ХОДОВАЯ

Схема запчастей Komatsu PW110R-1 - ПЕРЕДНИЙ МОСТ (/) ХОДОВАЯ
12
6
7
4
5
8
3
9
2
11
10
1
20
21
17
19
16
18
23
13
14
15
8
7
27
28
22
24
21
26
25
38
29
30
33
31
32
37
36
34
35

Артикул

Название

Примечание

Количество

\0

226-23-11001

FRONT AXLE, ASSY.

1

226-22-11721

HOUSING

1

226-22-11722

HOUSING

2

226-22-11741

HOUSING

2

226-22-11742

HOUSING

3

226-22-11640

BUSHING

4

226-22-11670

PIN, ASSY.

5

PIN

6

22E-23-11550

FITTING

7

22E-23-11990

PLUG

8

226-22-11350

BOLT

9

226-22-11930

SHIM, 0.150 mm

9

226-22-11931

SHIM, 0.150 mm

9

226-22-11930

SHIM, 0.150 mm

9

226-22-11940

SHIM, 0.200 mm

9

226-22-11941

SHIM, 0.200 mm

9

226-22-11940

SHIM, 0.200 mm

9

226-22-11950

SHIM, 0.500 mm

9

226-22-11951

SHIM, 0.500 mm

9

226-22-11950

SHIM, 0.500 mm

10

226-22-11650

RING

10

226-22-11651

BUSHING

10

DG2120600603

BUSHING

11

226-22-11690

SEAL

12

226-22-11660

COVER

13

226-22-11680

PIN, ASSY.

14

PIN

15

22E-23-11550

FITTING

16

226-22-11690

SEAL

17

226-22-11710

ARTICULATION

18

226-22-11882

CHECK BOLT

19

226-22-11890

NUT

20

226-22-11750

SEAL

20

226-22-11751

SEAL

21

226-22-11760

BEARING

22

21D-23-12641

WHEEL HUB

23

21D-23-11820

STEERING COLUMN

24

21D-23-11110

O-RING

25

226-22-11780

GEAR, RING

26

226-22-11870

RING

27

226-22-11791

SUPPORT

28

226-22-11920

PLATE

29

226-22-11850

STUD

30

226-22-11860

NUT

31

226-22-11820

PLANET WHEEL

32

226-22-11830

BEARING

33

226-22-11810

RING

34

226-22-11841

PLANET GEAR CARRIER

35

21D-23-12111

SCREW

36

21D-23-11970

PLUG

37

21D-23-11960

WASHER

38

21D-23-11850

NUT

Выбрано товаров: 52
