Запчасти Komatsu PW110R-1 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

Схема запчастей Komatsu PW110R-1 - КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА
16
19
14
10
16
17
29
37
30
13
36
35
30
11
14
12
10
38
44
39
43
45
10
31
34
15
10
33
32
16
25
17
19
18
23
26
27
28
24
41
21
42
22
48
1
2
3
4
40
5
7
8
6
10
46
9
10
46
47
20
a
a
c
c
b
b
d
d
d
b
c
a

Артикул

Название

Примечание

Количество

\0

21D-54-12304

OPERATOR'S CAB, ASSY.

\0

21D-54-12305

OPERATOR'S CAB, ASSY.

1

21D-54-13430

SEAL

2

21D-54-13661

FRAME, FRONT

3

21D-54-13680

SEAL, FRONT UPPER

4

21D-54-13670

GLASS, FRONT, UPPER

5

21D-54-13440

GLASS, FRONT, LOWER

6

21D-54-13630

BLOCK

7

21D-54-13640

RABBET

8

21D-54-13650

GASKET

9

01010-50816

BOLT

10

21D-09-73520

SPRING WASHER

11

21D-54-13731

LEVER, R.H.

12

21D-54-13741

LEVER, L.H.

13

21D-54-13790

CYLINDER

14

21D-09-23160

NUT

15

21D-54-13761

PIN

16

21D-54-13770

WASHER

17

01010-51012

BOLT

18

21D-54-13780

COVER

19

21D-54-13750

BUSHING

20

21D-54-13690

BUSHING

21

21D-54-13480

SPRING

22

21D-54-13720

LEVER

23

21D-54-13710

PIN

24

21D-54-14120

STRIKER

25

01643-31032

WASHER

26

01010-50616

BOLT

27

21D-09-73490

SPRING WASHER

28

21D-54-13580

WASHER

29

21D-54-13590

BLOCK

30

226-54-11780

GASKET

31

21D-54-13620

SPACER

32

01010-50825

BOLT

33

21D-54-13450

LATCH ASSY., R.H.

33

21D-54-13520

LATCH ASSY., L.H.

34

21D-54-13530

LATCH

35

21D-54-13480

SPRING

36

21D-54-13460

PIN

37

21D-54-13470

SLEEVE

38

21D-54-13490

PIN

39

21D-54-13510

KNOB

40

21D-54-14670

PLATE

41

21D-54-14680

HANDLE, R.H.

42

21D-54-14690

HANDLE, L.H.

43

01010-50820

BOLT

44

21D-09-74460

SPRING WASHER

45

21D-09-86190

COVER

46

01580-10806

NUT

47

21D-54-14710

PIN

48

21D-54-12110

KNOB

Выбрано товаров: 51
