Запчасти Komatsu PW110R-1 ЗАДН. МОСТ (/8) ХОДОВАЯ

\0

226-22-11000

REAR AXLE, ASSY.

1

22E-22-11110

O-RING

2

22E-22-11120

PLUG

3

22E-22-11130

COVER

4

22E-22-11140

GASKET

5

22E-22-11150

SHIM, 0.100 mm

5

22E-22-11180

SHIM, 0.150 mm

5

22E-22-11190

SHIM, 0.200 mm

5

22E-22-11160

SHIM, 0.300 mm

5

22E-22-11170

SHIM, 0.400 mm

6

21D-14-11540

BEARING

7

22E-22-11650

PLATE

8

21D-23-11210

PLUG

9

21D-14-11270

PROTECTION

10

21D-14-11280

SWITCH

11

21D-14-11290

WASHER

12

22E-22-11580

O-RING

13

22E-22-11410

BOLT

14

21D-14-11710

SPRING

15

21D-14-11680

BALL

16

21D-23-12350

PLUG

17

21D-14-11460

BEARING

18

22E-22-11620

GASKET

19

22E-22-11610

COVER

20

226-22-11210

FLANGE

21

22E-22-11640

O-RING

22

22E-23-12430

NUT

23

22E-22-11270

SCREW

24

226-22-11190

BOLT

25

22E-22-11290

SCREW

26

22E-22-11280

WASHER

27

21D-14-11910

STUD

28

226-22-11530

NUT
