Запчасти Komatsu PW110R-1 КОВШ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

226-70-11310

BUCKET, L=300 mm

1

226-70-11320

BUCKET, L=400 mm

1

226-70-11330

BUCKET, L=500 mm

1

226-70-11340

BUCKET, L=600 mm

1

226-70-11350

BUCKET, L=700 mm

1

226-70-11360

BUCKET, L=800 mm

1

226-70-11370

BUCKET, L=900 mm

1

226-70-11380

BUCKET, L=1000 mm

2

226-70-11410

TOOTH HOLDER (WELDED)

3

226-70-11420

TOOTH

4

226-70-11430

PIN

5

226-70-11440

RING
