Запчасти Komatsu PW100S-3B КОВШ (ВЕРТИКАЛЬН. ПАЛЕЦ¤ С РЕГУЛЯТОРОМ)(№-) КАТАЛОГИ ЗЧ

Схема запчастей Komatsu PW100S-3B - КОВШ (ВЕРТИКАЛЬН. ПАЛЕЦ¤ С РЕГУЛЯТОРОМ)(№-) КАТАЛОГИ ЗЧ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
15
16
17
18
19
15
16
17
18
19
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36
37
38
39
40
41
42

Артикул

Название

Примечание

Количество

1

202-70-63113

BUCKET

2

202-70-63121

PLATE (WELDED)

3

202-70-63190

ADAPTER (WELDED)

4

202-70-63132

PLATE,L.H. (WELDED)

5

202-70-63142

PLATE,R.H. (WELDED)

6

202-70-63250

PLATE (WELDED)

7

202-70-63241

PLATE (WELDED)

|7

202-70-63240

PLATE (WELDED)

8

205-70-74272

TOOTH

|8

203-70-43230

TOOTH,(FOR LONG LIFE)

9

205-70-74281

PIN

10

205-70-74291

LOCK

11

202-70-63161

CUTTER,L.H.

12

202-70-63171

CUTTER,R.H.

13

208-32-11231

BOLT

14

01803-02228

NUT

15

203-926-4112

BUCKET

16

203-926-2121

PLATE (WELDED)

17

203-926-3121

PLATE,L.H. (WELDED)

18

203-926-3131

PLATE,R.H. (WELDED)

19

203-70-43190

ADAPTER (WELDED)

15

203-926-4212

BUCKET

16

203-926-3221

PLATE (WELDED)

17

203-70-43131

PLATE,L.H. (WELDED)

18

203-70-43121

PLATE,R.H. (WELDED)

19

203-70-43190

ADAPTER (WELDED)

15

203-926-4312

BUCKET

16

203-926-3321

PLATE (WELDED)

17

203-70-43131

PLATE,L.H. (WELDED)

18

203-70-43121

PLATE,R.H. (WELDED)

19

203-70-43190

ADAPTER (WELDED)

15

203-927-4110

BUCKET

16

203-927-2120

LIP (WELDED)

17

203-927-2141

PLATE,L.H. (WELDED)

18

203-927-2131

PLATE,R.H. (WELDED)

19

203-70-43190

ADAPTER (WELDED)

20

203-70-43180

TOOTH

21

203-70-43212

PIN

22

203-70-43220

PIN

23

203-70-43260

CUTTER,L.H.

24

203-70-73270

CUTTER,R.H.

25

01802-02262

BOLT

26

01803-02228

NUT

27

202-920-5112

BUCKET

28

202-920-5131

PLATE (WELDED)

29

202-920-5140

PLATE,L.H. (WELDED)

|29

202-920-5122

PLATE,R.H. (WELDED)

30

203-70-43191

ADAPTER (WELDED)

31

203-70-43180

TOOTH

32

203-70-43212

PIN

33

203-70-43220

PIN

34

203-70-44470

O-RING

35

203-70-44380

PIN

36

01011-51670

BOLT

37

01580-11613

NUT

38

202-70-64250

SPACER

39

202-70-64240

PLATE

40

202-70-64210

SPACER¤ 0.5MM

|40

202-70-64220

SPACER¤ 1.0MM

41

01010-51470

BOLT

42

01643-31445

WASHER

Выбрано товаров: 61
