Запчасти Komatsu PF5-1 МОТОР ПОВОРОТА (/)(№-9) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|1

23S-26-00011

SWING MOTOR ASS'Y

1

TZ902S1001-00

HUB ASS'Y

2

TZHP00001-2

PLUG

|3

TZ902S1101-00

SPINDLE ASS'Y

3

SPINDLE

4

FLANGE

5

TZ900S1020-00

RING

6

TZ902S1102-00

GEAR ASS'Y

7

TZ900A1017-00

PIN

8

TZ850A1021-00

BEARING,BALL

9

TZ800A1019-00

BOLT

10

TZ901S1007-00

SPUR GEAR ASS'Y

11

TZ860A1014-00

PIECE

12

TZ860A1013-00

SNAP RING SET

13

04064-02512

RING,SNAP

14

TZ901S1006-00

GEAR,INPUT

15

04064-01710

RING,SNAP

16

TZ032021JR

BEARING,ROLLER

17

TZ900S1024-00

NUT

18

TZW16-13088

O-RING (KIT)

19

TZ-13516514

SEAL,OIL (KIT)

20

TZ902S1026-00

PLATE

21

TZPP0050-14

PIN,DOWEL

22

01010-62085

BOLT

23

TZJB1176-20

WASHER

24

23S-26-11121

PINION
