Запчасти Komatsu PF3W-1 КУЛАК И ПОПЕРЕЧНАЯ РУЛЕВ. ТЯГА ШАССИ¤ ТРАНСМИССИЯ¤ МОСТ¤ КОЛЕСА И ВОЗД. СИСТЕМА

|1

20D-22-40010

FRONT AXLE ASS'Y

1

20D-22-43520

KNUCKLE,L.H.

2

20D-22-43510

KNUCKLE,R.H.

3

22X-22-13530

BUSHING

4

20D-22-43810

PIN,KING

5

20D-22-43850

SHIM¤ 0.10MM

|5

20D-22-43860

SHIM¤ 0.15MM

|5

20D-22-43870

SHIM¤ 0.20MM

|5

20D-22-43880

SHIM¤ 0.50MM

6

01010-62045

BOLT

7

20D-22-43550

SPINDLE

8

20G-22-12570

BUSHING

9

20G-22-12590

SEAL,OIL

10

20D-22-42730

RETAINER

11

07000-02100

O-RING

12

01010-61840

BOLT

|13

20G-22-22511

JOINT ASS'Y,YOKE

13

20G-22-12531

SHAFT,YOKE

14

20G-22-22521

SHAFT,YOKE

15

20G-22-22691

SPIDER ASS'Y

16

20G-22-22561

FITTING,GREASE

17

20G-22-12551

RING,SNAP

18

20D-22-43340

YOKE,L.H.

19

20D-22-43320

YOKE,R.H.

20

20D-22-43310

ROD,TIE

21

01010-31265

BOLT

22

01580-01210

NUT

23

01602-01236

WASHER,SPRING

24

22X-22-13330

PIN

25

07020-00900

FITTING,GREASE

26

01598-02021

NUT

27

01643-32060

WASHER

28

20D-22-43570

STEERING ARM ASS'Y

29

04022-25045

PIN,DOWEL

30

07143-10404

BUSHING

31

07145-00040

SEAL,DUST

32

07020-00675

FITTING,GREASE

33

07020-00675

FITTING,GREASE

34

22X-22-13360

BOLT

35

01580-02016

NUT
