Запчасти Komatsu PC95R-2 USA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC95R-2 USA - ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
64
57
55
41
58
46
43
56
47
44
65
37
47
66
47
47
39
41
40
50
48
67
43
44
51
37
65
62
36
35
66
45
39
40
61
36
48
34
47
49
54
36
45
34
36
52
68
63
53
33
37
80
47
39
43
41
40
48
41
43
44
37
78
36
45
39
40
48
25
47
68
26
23
47
3
34
23
27
36
3
14
27
45
20
35
36
31
20
29
29
19
70
79
19
22
69
21
11
13
11
13
16
15
4
30
1
18
17
17
2
18
25
26
44
36
49
46

Артикул

Название

Примечание

Количество

\0

21D-01-11300

ENGINE, ASSY.

\0

21D-01-11301

ENGINE, ASSY.

1

YM123900-07910

LIFTER, ENGINE

2

YM26106-100202

SCREW

3

YM123907-11550

CAP VALVE

4

YM723907-11100

HEAD ASSY, CYLINDER

11

YM123907-11810

GUIDE VALVE

13

YM123907-11800

GUIDE VALVE

14

YM23876-020000

PLUG

15

YM23876-030000

PLUG

16

YM27241-400000

PLUG

17

YM123907-11100

VALVE, SUCTION

18

YM123907-11110

VALVE, EXHAUST

19

YM123907-11120

SPRING, VALVE

20

YM123907-11180

RETAINER, SPRING

21

YM124160-11340

SEAL, VALVE STEM

22

YM124950-11340

SEAL, VALVE EXHAUST

23

YM123907-11510

COLLECTOR, ASSY.

25

YM129150-11750

NUT

26

YM123907-11830

SCREW

27

YM27310-070001

COTTER

29

YM123907-11820

STUD

30

YM23876-005000

PLUG

31

YM24311-000120

O-RING

\31

YM123907-11340

SUPPORT, ASSY.

33

YM123907-11250

ROCKER SHAFT

34

YM123907-11260

SUPPORT

35

YM123907-11270

SUPPORT

36

YM123907-11280

WASHER

37

YM123907-11650

ROCKER SHAFT, SUCTION

39

YM129150-11230

SCREW

40

YM129150-11750

NUT

41

YM123907-11660

ROCKER SHAFT, EXHAUST

43

YM129150-11230

SCREW

44

YM129150-11750

NUT

45

YM123907-11900

RETAINER, VALVE

46

YM26226-080302

STUD

47

YM26106-080752

BOLT

48

YM26106-080902

BOLT

49

YM26306-080002

NUT

50

YM124160-01751

PLUG

51

YM123907-11320

BONNET ASSY., HEAD

52

YM123907-03010

PLATE

53

YM123907-03060

SPLASH-GUARD

54

YM123907-03070

SPLASH-GUARD

55

YM123907-03100

DIAPHRAGM

56

YM123907-03110

PLATE

57

YM123907-03120

PLATE

58

YM123907-03140

SPRING

61

YM123907-11310

GASKET

62

YM119640-61400

PLUG

63

YM22857-500100

SCREW

64

YM22857-500100

SCREW

65

YM124160-11360

PLUG

66

YM24311-000120

O-RING

67

YM24311-000320

O-RING

68

YM123907-11390

STUD

69

YM119802-11870

PROTECTION, NOZZLE

70

YM119625-11880

SEAT, NOZZLE

78

YM123900-07920

LIFTER, ENGINE

79

YM26106-100252

BOLT

80

YM977770-01212

GASKET, LIQUID

Выбрано товаров: 62
