Запчасти Komatsu PC95R-2 USA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC95R-2 USA - ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
36
44
32
1
57
32
25
34
49
32
36
58
53
59
54
45
51
46
26
46
48
38
47
35
36
52
42
39
34
31
43
29
38
35
36
41
34
27
31
43
28
38
29
35
40
41
28
34
31
32
43
30
38
35
41
28
55
31
43
29
39
24
41
22
19
20
23
21
18
13
16
56
17
12
9
4
60
11
5
8
7
15
14
2
3

Артикул

Название

Примечание

Количество

\0

21D-01-00020

ENGINE, ASSY.

1

YM123910-03090

PIPE

2

YM123900-13690

LIFTER

3

YM26106-100202

BOLT

4

YM723900-11100

HEAD,ASSY.

5

CYLINDER HEAD

7

YM123900-11080

SEAT

8

YM123900-11090

SEAT

9

YM119000-11810

GUIDE VALVE

11

YM23876-005000

PLUG

12

YM27241-400000

PLUG

13

YM26216-060302

STUD

14

YM123900-11100

VALVE, INLET

15

YM123900-11110

VALVE EXHAUST

16

YM123900-11120

SPRING

17

YM121850-11150

SEAL, VALVE

18

YM121850-11180

RETAINER, SPRING

19

YM119171-11370

CAP VALVE

20

YM119625-11870

PROTECTION, NOZZLE

21

YM119625-11880

SEAT, NOZZLE

22

YM119625-11900

RETAINER

23

YM27310-090000

COTTER

24

YM26366-060002

NUT

25

YM24311-000320

O-RING

26

YM123900-11200

ROCKER SHAFT, ASSY.

27

YM123900-11240

ROCKER SHAFT

28

YM119000-11280

SPRING

29

YM123900-11510

SUPPORT

30

YM123900-11520

SUPPORT

31

YM123900-11650

ROCKER SHAFT, SUCTION

32

YM129150-11230

SCREW

34

YM129150-11750

NUT

35

YM123900-11660

ROCKER SHAFT, EXHAUST

36

YM129150-11230

SCREW

38

YM129150-11750

NUT

39

YM22242-000180

RING, SNAP

40

YM26577-040162

SCREW

41

YM119593-11300

BOLT

42

YM26106-080702

BOLT

43

YM26366-080002

NUT

44

YM124160-01751

PLUG

45

YM123900-11331

BONNET ASSY., HEAD

46

YM129150-03070

SPLASH-GUARD

47

YM123900-03202

PLATE

48

YM123900-03210

GASKET

49

YM123900-03220

PIPE

51

YM123900-11310

GASKET

52

YM26022-050122

SCREW

53

YM124160-11360

PLUG

54

YM24311-000120

O-RING

55

YM123900-07920

LIFTER

56

YM26106-100252

BOLT

57

YM23000-041000

COLLAR

58

YM23297-350121

RETAINER

59

YM26106-120202

BOLT

60

YM26106-080142

BOLT

Выбрано товаров: 56
