Запчасти Komatsu PC95R-2 USA ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC95R-2 USA - ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ
28
28
31
28
28
31
33
28
28
31
59
28
58
57
28
58
32
3
5
57
17
44
15
18
43
28
29
10
58
59
58
22
41
6
24
45
30
12
22
41
4
26
56
23
25
52
22
14
2
6
13
22
53
24
35
1
9
20
47
13
34
42
7
42
46
50
55
54
13
21
48
52
51
49
19
13
A
B
B
C
C

Артикул

Название

Примечание

Количество

\0

21D-01-00020

ENGINE, ASSY.

1

YM119000-55600

FILTER

2

YM129470-55610

BODY

3

YM194180-51640

CLAMP

4

YM26106-100252

BOLT

5

YM26106-100142

BOLT

6

YM101304-59020

UNION

7

YM129957-59040

PIPE

9

YM119560-59110

PROTECTION

10

YM119560-59051

PIPE

12

YM119560-59110

PROTECTION

13

YM124766-59050

CLAMP

14

YM121750-59890

RETAINER

15

YM103854-59191

BOLT

17

YM124060-59380

PLUG

18

YM22190-060002

SPRING WASHER

19

YM121855-59880

JOINT

20

YM121855-59880

JOINT

21

YM121250-49110

JOINT

22

YM22190-120002

WASHER

23

YM23857-060000

BOLT

24

YM124766-59050

CLAMP

25

YM129957-59050

PIPE

26

YM129957-59120

PROTECTION

28

YM124066-59100

CLAMP

29

YM129495-59300

BOLT

30

YM129980-59530

JOINT

31

YM121250-59550

PIPE

32

YM124732-59562

PIPE

33

YM129150-59580

PLUG

34

YM121855-59880

JOINT

35

YM128300-59910

VALVE

41

YM22190-140002

SPRING WASHER

42

YM22190-140002

SPRING WASHER

43

YM22190-080002

GASKET

44

YM26106-080102

BOLT

45

YM120324-55750

WATER SEPARATOR

46

YM120324-55760

FILTER

47

YMX0582810173

GASKET

48

YMX0580121073

O-RING

49

YMX0311121522

BOLT

50

YMX0300120414

GASKET

51

YMX0313080110

BOLT

52

YMX0588080273

GASKET

53

YMX2740134001

COVER

54

YMX2540025002

TANK

55

YMX0600160122

SPRING

56

YMX0314080110

PLUG

57

YM121750-59910

JOINT

58

YM22190-140002

SPRING WASHER

59

YM23857-080000

BOLT

Выбрано товаров: 51
