Запчасти Komatsu PC95R-2 USA БОКОВ. КРЫШКА ДВИГ. ЧАСТИ КОРПУСА И КАБИНА

1

21D-54-11111

HOOD

2

01010-51025

BOLT

3

01643-31032

SPRING WASHER

4

21D-54-11590

GASKET

5

22E-54-11330

GASKET

6

226-54-11220

GASKET

7

21D-54-11121

COVER

8

01010-50820

BOLT

9

01643-30823

SPRING WASHER

10

21D-54-11810

GASKET

11

21D-54-11820

GASKET

12

21D-54-11560

HINGE

13

21D-54-11190

DAMPER

14

21D-09-85140

PIN, COTTER

15

226-54-11311

HOOD

16

226-54-11320

GASKET

17

20M-54-72250

CATCH

18

22E-54-11650

PUSH-BUTTON, ASSY.

19

22E-54-11660

SPACER

20

01252-40640

SCREW

21

01580-10605

NUT

22

226-54-11130

LOCK, ASSY.

23

21D-09-15150

SCREW

24

01580-10806

NUT

25

226-54-11160

SUPPORT

26

21D-54-11260

PIN

27

01643-31232

WASHER

28

22E-54-11270

NUT

29

21D-54-11830

GASKET

30

01010-51030

BOLT

31

22E-46-11430

TOOL BOX, ASSY.

32

21D-04-11330

RETAINER

33

01010-50825

BOLT

34

01643-30823

SPRING WASHER

35

21D-09-23160

NUT

36

21D-54-11740

GASKET

37

21D-54-11750

GASKET

38

21D-54-11840

SUPPORT

39

01010-51025

BOLT

40

01643-31032

SPRING WASHER

41

22E-06-11950

HORN

42

01435-00825

BOLT

43

21D-09-21440

NUT

44

21D-46-11220

SHEET

45

21D-46-11310

PROTECTION

46

21D-54-11660

SHIM

47

22E-54-11640

SHIM

48

21D-09-81700

COLLAR
