Запчасти Komatsu PC95R-2 USA КЛАПАН PPC(ДЛЯ ХОДА) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

702-16-01831

PPC VALVE

1

BODY VALVE

2

VALVE

3

702-16-51140

SHIM, 0.300 mm

4

702-16-53420

SPRING

5

702-16-53140

STOPPER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-51270

GASKET

9

702-16-54170

COLLAR

10

07000-12020

O-RING

11

702-16-57420

PLATE

12

LINK

13

702-16-54280

SEAL DUST

14

702-16-54430

BUSHING

15

04025-00432

SPRING PIN

16

702-16-57321

COVER

17

01010-80855

BOLT

18

01643-30823

SPRING WASHER

19

01010-80816

BOLT

20

702-16-54351

WASHER (1.0 mm)

20

702-16-54341

WASHER (1.3 mm)

20

702-16-54331

WASHER (1.6 mm)

21

LINK

22

01252-60525

BOLT

23

702-16-54511

SLIDER

24

04025-00420

SPRING PIN

25

LINK

26

01224-40612

SCREW

27

PLUG

28

PLUG

\28

702-16-54505

DAMPER, ASSY.

29

BODY

30

PISTON

31

O-RING

32

WASHER

33

RING, SNAP

34

PLUG

35

04022-04016

PIN

36

04022-04010

PIN
