Запчасти Komatsu PC95R-2 USA ЦИЛИНДР 2-Й СТРЕЛЫ, ЛЕВ. РАБОЧЕЕ ОБОРУДОВАНИЕ

1

226-61-11340

2ND BOOM CYLINDER, ASSY.

2

21D-61-16121

PISTON ROD

3

21D-61-16170

BUSHING

4

21D-09-13110

SCREW

5

21D-09-73700

SPRING WASHER

6

21D-61-16130

COVER

7

21D-61-12140

RING

8

21D-61-16140

CYLINDER HEAD

9

21D-61-16151

PISTON

10

21D-09-24480

NUT

11

21D-61-16111

CYLINDER

12

21D-61-16180

BUSHING

\12

226-61-11320

KIT, GASKET

13

21D-09-67120

GASKET

14

07145-00050

SEAL, DUST

15

855021824

O-RING

16

855080824

RING, WEAR

17

855661048

GASKET

18

855021158

O-RING

19

21D-09-67350

PACKING ROD

20

21D-09-67440

GASKET

21

21D-09-67380

GASKET

22

21D-09-69980

O-RING

23

21D-09-65170

RING, WEAR

24

21D-09-67230

PACKING ROD

25

855661206

GASKET

26

21D-09-89140

FITTING

27

226-61-11331

PIPE

28

21D-09-69870

O-RING

29

21D-09-69770

O-RING

30

01252-40825

SCREW

31

21D-09-73690

SPRING WASHER

32

226-61-11110

FLANGE

33

21D-09-69870

O-RING

34

21D-09-69770

O-RING
