Запчасти Komatsu PC95R-2 КОЛЕНВАЛ И ПОРШЕНЬ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC95R-2 - КОЛЕНВАЛ И ПОРШЕНЬ ДВИГАТЕЛЬ
16
14
23
22
23
27
11
29
24
13
28
10
5
1
4
6
3
7
8
9

Артикул

Название

Примечание

Количество

\0

21D-01-11300

ENGINE, ASSY.

\0

21D-01-11301

ENGINE, ASSY.

1

YM123900-21000

CRANKSHAFT, ASSY.

3

YM129900-21200

GEAR, CRANKSHAFT

4

YM121850-21290

PIN

5

YM121850-21920

PIN

6

YM22512-070140

KEY

7

YM129900-21640

WASHER

8

YM123900-21650

PULLEY

9

YM121850-21680

BOLT

10

YM121850-21130

BOLT

11

YM123900-21580

FLYWHEEL, ASSY.

13

YM127410-21480

GEAR, RING

14

YM123907-22090

PISTON, ASSY.

14

YM723907-22910

ASSY, PISTON (+0.25 mm)

16

YM123907-22050

RING SET, PISTON

16

YM723907-22950

RING SET (+0.25 mm)

22

YM119173-22300

PIN

23

YM22252-000370

RING, SNAP

24

YM123900-23000

CONNECTING ROD, ASSY.

27

YM123900-23910

BUSH,IDLE GEAR (REPAIR PART)

28

YM123900-23200

BOLT

29

YM123900-23600

BEARING

29

YM123900-23610

BEARING (--0.25 mm)

Выбрано товаров: 24
