Запчасти Komatsu PC95R-2 БОКОВ. КРЫШКА ДВИГ. ЧАСТИ КОРПУСА И КАБИНА

1

21D-54-11990

HOOD, L.H.

2

01010-51025

BOLT

3

01643-31032

WASHER

4

21D-54-11590

GASKET

5

21D-54-11113

HOOD, R.H.

6

21D-54-11970

GASKET

7

21D-54-11122

FLANGE

8

01010-50820

BOLT

9

01643-30823

SPRING WASHER

10

22E-54-11370

GASKET

11

226-54-11450

HINGE

12

21D-54-11192

DAMPER

13

21D-09-85140

PIN, COTTER

14

226-54-11312

HOOD

14

226-54-11313

HOOD

15

226-54-11440

GASKET

16

20M-54-72250

BOOT

17

22E-54-11650

PUSH-BUTTON, ASSY.

18

22E-54-11660

SPACER

19

21D-09-14120

SCREW

20

01580-10605

NUT

21

226-54-11130

LOCK, ASSY.

22

21D-09-15150

SCREW

23

01580-10806

NUT

24

22E-54-11360

SUPPORT

25

21D-54-11260

PIN

26

01643-31232

WASHER

27

22E-54-11270

NUT

28

01010-51030

BOLT

29

22E-46-11440

TOOL BOX, ASSY.

30

01010-51016

BOLT

31

226-54-11241

GASKET

32

21D-54-11750

GASKET

33

01435-01020

SCREW

34

21D-54-11870

GASKET

35

21D-09-81700

COLLAR

36

21D-54-11660

SHIM

37

22E-54-11640

SHIM

38

21D-54-15240

COVER

39

01643-30823

SPRING WASHER

40

22E-54-11430

SUPPORT
