Запчасти Komatsu PC95R-2 РЕГУЛЯТОР ДВИГАТЕЛЬ

\0

21D-01-00021

ENGINE, ASSY.

\0

YM123911-51040

PUMP, ASSY.

\0

GOVERNOR, ASSY.

1

YMX1540621600

CAP

2

YMX0292016010

NUT

3

YMX1540006400

HOUSING

4

YMX0296325070

O-RING

5

YMX1540072900

PLUG

6

YMX1540070200

ADAPTOR

7

YMX0200181840

BOLT

8

YMX1543501900

PLATE

9

YMX0290106810

BOLT

10

YMX1540112300

NUT

11

YMX1540110100

NUT

12

YMX1540132320

SCREW

13

YMX0141108440

SPRING WASHER

14

YMX1545001020

COVER

15

YMX1543210400

BUSHING

16

YMX1540313000

SCREW

17

YMX1392060600

NUT

18

YMX1540360300

PLUG

19

YMX0201065040

BOLT

20

YMX1540100200

SCREW

21

YMX0201063840

BOLT

22

YMX1530205220

LIMITER

23

YMX1540635100

COVER

24

YMX0290206260

BOLT

25

YMX0290206260

BOLT

26

YMX0200062040

BOLT

27

YMX0200061640

BOLT

28

YMX1541010020

WEIGHT ASSY., GOVERNOR

29

YMX0258031610

KEY

30

YMX0293212020

SPRING WASHER

31

YMX0292312030

NUT

32

YMX1541230120

SLEEVE

33

YMX0293110010

SHIM

33

YMX0293110180

SHIM

33

YMX0293110190

SHIM

33

YMX0293110210

SHIM

33

YMX1394100000

SHIM, 0.500 mm

33

YMX1394100100

SHIM, 1.500 mm

33

YMX1394103000

SHIM, 2.000 mm

33

YMX1394103100

SHIM, 3.000 mm

33

YMX1394103200

SHIM, 4.000 mm

42

YMX1541502900

SPRING

43

YMX1541540701

SPRING

44

YMX1541580920

CAPSULE

45

YMX1540111700

NUT

46

YMX0265121540

GASKET

47

YMX1541591200

NUT

48

YMX1541856120

SPRING

49

YMX0292016080

NUT

50

YMX1542006920

LEVER

51

YMX1542044300

BUSHING

52

YMX0296318020

O-RING

53

YMX0160101640

RING, SNAP

54

YMX1396110000

GASKET

55

YMX1394110000

SHIM

56

YMX0293111070

SHIM

57

YMX1542044400

BUSHING

58

YMX0258031310

KEY

59

YMX1542062800

COLLAR

60

YMX1542060200

SPRING WASHER

61

YMX1542163820

LEVER

62

YMX1542303920

LEVER

63

YMX0160100540

RING, SNAP

64

YMX1542364100

LEVER

65

YMX1542370100

PIN

66

YMX1543963120

LEVER

67

YMX1543827920

LEVER

68

YMX0200061640

BOLT

69

YMX1543142600

SPRING

70

YMX0296310030

O-RING

71

YMX1543220100

CAP

72

YMX1543265020

LEVER

73

YMX1543277400

SPRING

74

YMX0293110520

SHIM

74

YMX0293110530

SHIM, 0.250 mm

74

YMX0293110540

SHIM, 0.300 mm

74

YMX0293110550

SHIM, 0.350 mm

74

YMX0293110560

SHIM, 0.400 mm

74

YMX0293110570

SHIM, 0.500 mm

80

YMX1543900000

GASKET

81

YMX1543900300

GASKET

82

YMX0296352020

O-RING

83

YMX0265061040

GASKET

84

YMX1540352800

CAP NUT

85

YMX1543587200

SUPPORT

86

YMX0265182240

GASKET

87

YMX1541883320

SPRING

88

YMX1540621300

CAP

89

YMX1540107200

BOLT

90

YMX1540108100

BOLT
