Запчасти Komatsu PC95R-2 УПРАВЛЯЮЩ. КЛАПАН (/7) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
№
Артикул
Название
Примечание
Количество
\0
723-29-11401
CONTROL VALVE, ASSY.
\0
723-20-70400
VALVE, ASSY.
1
SLEEVE
2
VALVE
3
SPRING
4
PLUG
5
RING
6
O-RING
7
07002-12434
O-RING
8
07000-12016
O-RING
9
07001-02016
RING, WEAR
10
07000-11009
O-RING
11
07001-01009
RING, WEAR
\11
709-20-55200
RELIEF VALVE, ASSY.
12
SLEEVE
13
VALVE
14
VALVE
15
SPRING
16
SCREW
17
SPRING
18
RING
19
NUT
20
700-22-11410
O-RING
21
700-80-64220
RING, WEAR
22
07002-12434
O-RING
23
O-RING
\23
723-20-61800
RELIEF VALVE, ASSY.
24
SLEEVE
25
VALVE
26
VALVE
27
SPRING
28
SCREW
29
SPRING
30
RING
31
NUT
32
700-22-11410
O-RING
33
700-80-64220
RING, WEAR
34
07002-12434
O-RING
35
O-RING
\35
709-70-77100
SAFETY VALVE, ASSY.
36
SLEEVE
37
PLUG
38
VALVE
39
PISTON
40
VALVE
41
SPACER
42
NUT
43
NUT
44
700-22-11410
O-RING
45
700-80-64220
RING, WEAR
46
07002-12434
O-RING
47
O-RING
48
O-RING
49
GASKET
50
GASKET
51
SPRING
52
SPRING
Выбрано товаров: 57
