Запчасти Komatsu PC95R-2 ЭЛЕКТРИКА (ЛИНИЯ ДВИГАТЕЛЯ) КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

226-06-11160

WIRING HARNESS

2

226-06-11320

COVER

3

226-06-11330

KNOB

4

226-06-11340

PLATE

5

01010-50630

BOLT

6

21D-09-73490

SPRING WASHER

7

01580-10605

NUT

8

22E-06-11640

RELAY HOLDER

9

226-06-11350

RELAY

10

22E-06-11570

FUSE BOX

11

22E-06-11580

COVER

12

22E-06-11590

FUSE 30A

12

22E-06-11610

FUSE 40A

12

22E-06-11620

FUSE 50A

12

22E-06-11630

FUSE 60A

13

21D-09-73480

SPRING WASHER

14

21D-09-21420

NUT

15

226-06-11380

EC. POWER BOX

16

YM119632-77920

TIMER 1''

17

YM128300-77920

TIMER 15''

18

YM129100-77910

RELAY

19

226-06-11170

SUPPORT

20

01010-50816

BOLT

21

01643-30823

SPRING WASHER

22

21D-09-81640

HOSE-CLAMP

23

21D-06-11980

CABLE

24

01010-51020

BOLT

25

01643-31032

SPRING WASHER

26

226-06-11180

SUPPORT

27

01010-51020

BOLT

28

01643-31032

SPRING WASHER

29

22E-06-11860

TEMPERATURE TRANSMITTER

30

21D-54-11850

SUPPORT

31

01435-00820

SCREW
