Запчасти Komatsu PC95-1 USA КОЛЕНВАЛ - ПОРШЕНЬS И ШАТУНS ДВИГАТЕЛЬ

1

6810-31-1200

KIT, CRANKSHAFT, ASSY.

2

6810-21-8110

KIT, BEARING

2

6810-21-8120

KIT, BEARING (--0.25 mm)

2

6810-21-8130

KIT, BEARING (--0.50 mm)

2

6810-21-8140

KIT, BEARING (--0.75 mm)

3

6810-21-8240

KIT, BEARING

3

6810-21-8250

KIT, BEARING (--0.25 mm)

3

6810-21-8260

KIT, BEARING (--0.50 mm)

3

6810-21-8270

KIT, BEARING (--0.75 mm)

4

6810-21-8190

THRUST WASHER

4

6810-21-8210

THRUST WASHER (+0.19 mm)

5

6810-21-8220

THRUST WASHER

5

6810-21-8230

THRUST WASHER (+0.19 mm)

6

6810-31-3150

CONNECTING ROD, ASSY. (HIGH GRADE)

6

6810-31-3160

CONNECTING ROD, ASSY. (INTERM. GRADE)

6

6810-31-3170

CONNECTING ROD, ASSY. (INTERM. GRADE)

6

6810-31-3180

CONNECTING ROD, ASSY. (LOW GRADE)

7

6810-31-3190

BUSHING

8

6810-31-3210

SCREW

9

6810-31-3140

NUT

10

6810-31-3220

SLEEVE

12

6810-31-2160

KIT, PISTON

12

6810-31-2190

KIT, PISTON (+0.5 mm)

12

6810-31-2210

KIT, PISTON (+1.0 mm)

13

6810-31-2170

CIRCLIP

14

6810-31-2180

RING KIT

14

6810-31-2220

RING KIT (+0.50 mm)

14

6810-31-2230

RING KIT (+1.0 mm)

15

6810-31-1110

GEAR, CRANKSHAFT

16

6810-31-1120

KEY
