Запчасти Komatsu PC95-1 СИСТЕМА СМАЗКИ МАСЛ. НАСОС ДВИГАТЕЛЬ

1

6810-21-5100

LUBRICATING OLIO SUMP

2

6810-21-5290

INSERT

3

6810-21-5110

INSERT

7

6810-21-5140

GASKET

8

6810-21-5151

BRIDGE PIECE

10

6810-21-5160

SCREW

14

6810-21-5170

SCREW

15

6810-21-1330

BOLT

16

6810-51-6111

PIPE, OIL

17

6810-51-6120

GASKET

18

6810-51-6130

SCREW

25

6810-21-5180

PIPE

26

6810-21-5190

NUT

30

6810-21-6110

CLAMP

31

6810-21-5210

COTTER

35

6810-21-6120

SUPPORT

36

6810-21-6130

SCREW

37

6810-21-6140

WASHER

38

6810-21-5220

CLAMP

39

6810-21-5230

PLATE

40

6810-21-3270

SCREW

41

6810-21-3270

SCREW

42

6810-21-5240

NUT

43

6810-21-5250

WASHER

44

6810-21-5261

PLUG

45

6810-21-5210

COTTER

51

6810-21-5270

SCREW

59

6810-21-5280

DIPSTICK

60

6810-21-6210

SEAL, OIL

64

6810-21-6180

PLATE

65

6810-21-6190

GASKET

66

6810-21-3270

SCREW

67

21D-09-86240

GASKET (ONLY FOR TBG)

68

21D-01-11160

VALVE (ONLY FOR TBG)

69

21D-01-11170

UNION (ONLY FOR TBG)
