Запчасти Komatsu PC95-1 УПРАВЛЯЮЩ. КЛАПАН (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

21D-64-10000

CONTROL VALVE, ASSY.

\0

21D-64-11410

2-SPOOL CONTROL VALVE, ASSY.

1

21D-64-11180

COVER

2

21D-64-11190

SCREW

3

01252-40512

SCREW

4

21D-64-11280

SPRING, ASSY.

5

SPOOL, SWING

6

21D-64-11230

COVER

7

21D-64-11240

KIT, GASKET

8

WASHER

9

O-RING

10

21D-64-11220

SPRING, ASSY.

11

SPOOL, BLADE

12

21D-64-11340

ANTICAVITATIION VALVE

13

21D-64-11350

KIT, GASKET

14

21D-64-11360

PLUG

15

21D-64-11370

KIT, GASKET

16

21D-64-11140

ANTICAVITATIION VALVE

17

21D-64-11100

PRESSURE RELIEF VALVE

18

21D-64-11110

KIT, GASKET

19

21D-62-15560

PLUG

20

21D-09-69910

O-RING

21

21D-62-15470

PLUG

22

21D-09-69910

O-RING

23

21D-09-69790

O-RING

24

21D-09-65990

RING, WEAR

25

21D-64-11130

PLUG

26

21D-09-54900

PRESSURE TAKE-UP

27

21D-09-73160

GASKET
