Запчасти Komatsu PC88MR-8 E- АККУМУЛЯТОР БЕЗ АККУМУЛЯТОР DISCONNECT ПЕРЕКЛЮЧАТЕЛЬ ЭЛЕКТРИКА

1

08001-2080D

BATTERY, WET. . . . . . . . . . . . . .

|$1

08000-00000

TERMINAL, POSITIVE (+)

|$2

08000-00001

TERMINAL, NEGATIVE (-)

2

22P-06-11121

BRACKET

3

22P-06-11550

BRACKET

4

22B-06-21450

BOLT

5

419-43-17920

WASHER

6

22P-06-11131

SHEET

7

22P-06-11820

PLATE

8

01010-81225

BOLT

9

01643-31232

WASHER

10

08028-48030

CABLE, GROUND

11

01010-81045

BOLT

12

01643-31032

WASHER

13

195-33-11220

SPACER

14

08038-22009

CAP, TERMINAL

15

22P-06-11680

CABLE

16

08038-42009

CAP, TERMINAL

17

20U-06-21680

COVER, TERMINAL

18

08028-GH050

CABLE, GROUND

19

14X-06-12280

COVER

20

08038-04030

CAP, TERMINAL

21

04434-51712

CLIP

22

01010-81220

BOLT

23

01643-31232

WASHER

24

22P-06-11141

CABLE

25

08038-00035

CAP, TERMINAL

26

08038-04030

CAP, TERMINAL

27

04434-51712

CLIP

28

01010-81220

BOLT

29

01643-31232

WASHER

30

01010-81245

BOLT

31

01643-31232

WASHER

32

20Y-01-21260

SPACER

33

04434-52512

CLIP

34

07095-20318

CUSHION

35

201-06-61370

GROMMET

36

22P-06-11540

GROMMET

37

04434-51712

CLIP

38

01010-81260

BOLT

39

01643-31232

WASHER

40

20Y-03-11220

COLLAR

41

01010-81220

BOLT

42

01643-31232

WASHER
